FSD 350

The FSD 350 is the Ferretti Security Division Fast Patrol Vessel. This 35-metre craft has a displacement of 125 tons and is one of FSD’s most imposing platforms. Fitted with two 3700 hp engines operating Rolls-Royce KaMeWa waterjets, the boat is designed for speeds of over 45 knots; the CODAG (Combined Diesel And Gas) version can reach exceptional top speeds of over 55 knots. She can also carry a Rigid Hull Inflated Boat (RHIB) of up to 7.5 m in length on a dedicated ramp positioned at the stern.

FSD 350 FAST PATROL Vessel

Main size:
  • Overall length (standard ISO 8666): 116ft. 1in. / 35.37m
  • Hull lenght (standard ISO 8666): 107ft. 2in / 32.67 m.
  • Waterline lenght (boat fully laden): 92 Ft. 0in / 28.04 m.
  • Maximun beam: 23 Ft. 7in / 7.20 m.
  • Depth under the keel (boat fully laden): 4Ft. 3in / 1.3 m.
  • Displacement laden: 131.8 ton. / 261248 lb.
  • Displacement unladen: 106 ton. / 222667 lb.
  • Maximum number of person on board: 14

Propulsion, range and speed:
2 * MTU 16V 2000 M90 - 3700 mHp / 2720 kW at 2100 g/min + 2* Kamewa 71SIII waterjets, 1 * ETF50 power 5100HP. with Kamewa 56BIII booster waterjet
  • Maximum speed @ 1/3 load: 55 knots
  • Maximum speed @ full load: 50 knots
  • Patrolling speed @ full load: 33 knots
  • Maximum speed: 454 m.n.
  • Patrolling speed: 770 m.n.

Technical data:
  • Hull type: 15,1° deadrise, monohedron.
  • Fuel tank capacity: 25000 lt. / 6605 US gals.
  • Water tank capacity: 3000 lt. / 793 US gals.
The top performance is estimated at the following conditions: Standard version displacement of the boat at 1/3 of load. clean hull . 25'C air temperature good weather conditions. 6 persons on board.

FSD 350 FAST PATROL Vessel
