FSD 195

FSD 195, made by  Ferretti Security Division, is a displacing 20-metre Fast Patrol Vessel delivering high-performances , displacing around 36 tons that can comfortably reach speeds of 55 knots with a range of 500+ miles. She is equipped with two 1900 hp MAN engines and can be fitted with a variety of different equipment as per the customer’s requirements.

FSD 195 FAST PATROL VESSEL

Main size:
  • Overall length (standard ISO 8666): 65,9 Ft. / 20,04 m.
  • Hull lenght (standard ISO 8666): 64,0 Ft. / 19,50 m.
  • Waterline lenght (boat fully laden): 49,3 Ft. / 15,00 m.
  • Maximun beam: 16,5 Ft. / 5,00 m.
  • Depth under the keel (boat fully laden): 3,11 Ft. / 1,20 m.
  • Displacement laden: 38,62 ton. / 85143 lb.
  • Displacement unladen: 32,50 ton. / 71650 lb.
  • Maximum number of person on board (crew: 4pp): 8

Propulsion, range and speed:
2 x MAN 12V 1900 HP - power 1900 mhp / 1397 kW at 2300 RPM+ surface drives model TS85B.
  • Maximum speed @ 1/3 load: 54 knots
  • Maximum speed @ full load: 50 knots
  • Patrolling speed @ full load: 35 knots
  • Maximum speed: 380 m.n.
  • Patrolling speed: 525 m.n.

Technical data:
  • Hull type: 17°deadrise warped hull with spray rails.
  • Fuel tank capacity: 5500 lt. / 1453 US gals.
  • Water tank capacity: 500 lt. / 132 US gals.
The top performance is estimated at the following conditions: Standard version displacement of the boat at 1/3 of load, clean hull , 25'C air temperature good weather conditions, 4 persons on board.

FSD 195 FAST PATROL Vessel



image image



FSD 195 FAST PATROL VESSEL
